GSB-OP Flange spherical bearings - CSB® Plastic Bearing Technology

Product properties

● Housing made of high strength and shape-stable M163
● Ball studs made of coating znie steel, 304 stainless steel is available
● External thread design
● Maintenance-free and corrosion-resistant
● Easy connection - easy assembly
● Fits directly and space-saving

Standard products

GSB-OP Flange spherical bearings

Part no.:

M [mm]：

m [mm]：

H [mm]：

Ag [mm]：

A3 [mm]：

l [mm]：

D4 [mm]：

W [mm]：

*Lead time [wks]：

Shop now

Dimensions

▊GSB-OP Flange spherical bearings load capacity

Part No.	Max. axial static load		Max. radial static load		Weight
Part No.	Short-term [N]	Long-term [N]	Short-term [N]	Long-term [N]	[g]
GSB-OP-06	350	175	150	75	10.6
GSB-OP-08	750	375	250	125	23.1
GSB-OP-10	1200	600	140	70	41.2

GSB Flange spherical bearings

● Maintenance-free and dry operation
● Resistant to dust and dirt
● Absolute corrosion resistance
● Compensation of misalignment errors

CSB®GSB-OP Flange spherical bearings

Type PDF

Size 463KB

Time 09-2021

No. CSB/CAT.062E

download
