TEFPLAS® Fluoroplastic Bearings

Product properties

●Standard material of sliding layer: TEFPLAS® B, Available materials: Lower starting friction TEFPLAS® G and FDA grade TEFPLAS® E & TEFPLAS® P

●Shell made of aluminum, available stainless steel

●Self-lubricating, maintenance-free

●Smooth operation, low noise

●High-speed operation and longer life

●Operation temperature ±200℃

●Suitable for rotation, swing and linear motion


ALB Fluoroplastic bearings
ALB Fluoroplastic bearings

●Sliding layer material: TEFPLAS® B

●Self-lubricating, maintenance-free

●Smooth operation, low noise

●Split design, low cost

more
ALBP High-precision sliding bearings
ALBP High-precision sliding bearings

●Sliding layer with FDA grade material TEFPLAS® P

●High precision requirement

●Self-lubricating, maintenance-free

●Smooth operation, low noise

more
ALBB Fluoroplastic bearings
ALBB Fluoroplastic bearings

●Standard material of sliding layer: TEFPLAS® B

●Self-lubricating, maintenance-free

●Smooth operation, low noise

●High-speed operation and longer life

more
ALBG Fluoroplastic bearings
ALBG Fluoroplastic bearings

●Liner materials: TEFPLAS®

●Self-lubricating, maintenance-free

●Smooth operation, low noise

●High-speed operation and longer life

more
ALG Fluoroplastic bearings
ALG Fluoroplastic bearings

●Liner materials: TEFPLAS®

●Self-lubricating, maintenance-free

●Smooth operation, low noise

●Split design, low cost

more
ALBE Fluoroplastic bearings
ALBE Fluoroplastic bearings

●Sliding layer with FDA grade material TEFPLAS® E

●Self-lubricating, maintenance-free

●Smooth operation, low noise

●High-speed operation and longer life

more
ALBW Thrust Washers
ALBW Thrust Washers

●Standard material of sliding layer: TEFPLAS® B

●Self-lubricating, maintenance-free

●Smooth operation, low noise

●High-speed operation and longer life

more

Sliding layer materials TEFPLAS®

TEFPLAS® B is a standard sliding layer material. It combines high load bearing and wear resistance performance , suitable for hard shafts ≥HRC35 or hard anodized aluminum shafts.

TEFPLAS® G has excellent wear resistance, lower starting friction force, suitable for hard shafts or hard anodized aluminum shafts.

TEFPLAS® E FDA food contact safety materials, suitable for stainless steel shaft or aluminum shaft.

TEFPLAS® P FDA food contact safety materials, suitable for soft shafts.

Materials

Friction coef.

dry [u]

Max. static load

[Mpa]

Max. dynamic load

[Mpa]

Max. PV

[N/mm2xm/s]

Max. Speed ,dry [m/s]

Operation temp.

[℃]

ContinuousIntermittent
TEFPLAS® B0.10-0.2520100.71.54.0±200
TEFPLAS® G0.10-0.201680.61.03.0±200
TEFPLAS® E0.05-0.181260.41.02.0±200
TEFPLAS® P0.05-0.181260.51.02.0±200

***For operation under extreme high temperature, it is necessary to consider increasing the fitting clearance to avoid stagnation caused by the high temperature expansion of the shaft and bearing. Please contact us.

Precision shafts
Precision shafts

AS: Hard anodized aluminum shaft, the best shaft for LIN linear bearings; CS: Hard-chromed steel shaft, the effective-cost shaft; ES: 304 Stainless steel shaft, the best for chemical liquid; Shaft end processing service...

more
