HN Linear guide rails

Product properties

● The installation holes are consistent with the standard ball guide rails

● Made of hard anodized surface of aluminum alloy

● Available longer design by the guide rails connection

● Maintenance-free with HNC roller carragies

● Compact design carriages, self-lubricating and maintenance-free

● Very suitable for high speed applications, the speed up to 10m/s

● Smooth moving, Driving force is about 10% of sliding carriages

HN01 Linear guide rails

● The installation holes are consistent with the standard ball guide rails

● Made of hard anodized surface of aluminum alloy

● Available longer design by the guide rails connection

HNC01 Roller carriages

● Compact design carriages, self-lubricating and maintenance-free

● Very suitable for high speed applications, the speed up to 10m/s

● Smooth moving, Driving force is about 10% of sliding carriages

Installation
Downloads

▊Eccentric forces

The rolling friction design of HR linear guide is not limited by the 2:1 rule of sliding guide, but it should be noted that the force on the roller caused by the eccentric force increases exponentially with the leverage effect.

Type PDF

Size 150KB

Time 02-2025

No. CSB/CAT.069E

download
