BAL Spherical balls for bearing housings

Product properties

● High load spherical ball solutions

● Standard ball material EPB13, avaliable FDA grade material EPB6 or 250℃ material EPB10

● Self-lubricated and maintenance free

● For various metal bearing housings

● Vibration dampening

● Good chemical resistance

● No noise and light weight



BAL Spherical balls for bearing housings
Dimensions

Load capacities of BAL Spherical balls for metal bearing housings-Standard material EPB13 balls

Part No.

Max. radial static compressive strength
Max. axial static tensile strength
Weight
[KN]
[KN]
[g]
BAL-17-17-EPB13
10.07.536
BAL-20-14-EPB13
9.55.030
BAL-20-17-EPB13
11.57.534
BAL-25-15-EPB13
13.05.535
BAL-25-17-EPB13
14.57.539
BAL-30-16-EPB13
16.56.553
BAL-30-19-EPB13
19.59.562
BAL-35-17-EPB13
20.57.576
BAL-35-20-EPB13
24.010.589
BAL-40-18-EPB13
25.08.598
BAL-40-21-EPB13
29.012.0114

Load capacities of BAL Spherical balls for metal bearing housings-FDA grade material EPB6 balls

Part No.

Max. radial static compressive strength
Max. axial static tensile strength
Weight
[KN]
[KN]
[g]
BAL-17-17-EPB6
10.07.536
BAL-20-14-EPB6
9.55.030
BAL-20-17-EPB6
11.57.534
BAL-25-15-EPB6
13.05.535
BAL-25-17-EPB6
14.57.539
BAL-30-16-EPB6
16.56.553
BAL-30-19-EPB619.59.562

Load capacities of BAL Spherical balls for metal bearing housings-High temperature material EPB10 balls

Part No.

Max. radial static compressive strength
Max. axial static tensile strength
Weight
[KN]
[KN]
[g]
BAL-17-17-EPB10
36.026.036
BAL-20-14-EPB10
35.018.030
BAL-20-17-EPB10
42.526.034
BAL-25-15-EPB10
46.520.035
BAL-25-17-EPB10
53.026.539
BAL-30-16-EPB10
60.023.053
BAL-30-19-EPB10
71.032.562
BAL-35-17-EPB10
74.027.076
BAL-35-20-EPB10
87.537.089
BAL-40-18-EPB10
90.030.098
BAL-40-21-EPB10
105.041.0114
